Integra DRX-5.4 9.2-Channel Network AV Receiver

Exceptional Home Theater. Engineered for Performance and Integration.

The Integra DRX-5.4 brings sophisticated home theater performance, powerful amplification, and professional-grade integration capabilities together in one remarkably versatile AV receiver.

Designed for discerning listeners and custom-installed entertainment systems, the DRX-5.4 delivers nine channels of high-current amplification, rated at 120 watts per channel into 8 ohms with two channels driven.

From the subtleties of a beautifully recorded concert to the dynamic impact of an action-packed film, the DRX-5.4 provides the control, detail, and engaging sound that make exceptional home entertainment possible.

Immersive Surround Sound

Experience movies, music, and games with the remarkable realism of Dolby Atmos and DTS.

With nine channels of onboard amplification, the DRX-5.4 can power a 5.2.4-channel Dolby Atmos system or a 7.2.2-channel configuration.

Its 11.2-channel processing and preamplifier outputs provide additional flexibility, allowing expansion to a 7.2.4-channel system with compatible external amplification.

THX Certified Select performance and IMAX Enhanced compatibility further complement its impressive home theater capabilities.

Dirac Live Room Correction Included

Even excellent speakers can be affected by room acoustics.

The DRX-5.4 includes full-bandwidth Dirac Live room correction, allowing precise measurement and calibration of your speakers within the listening environment.

By optimizing frequency response and timing, Dirac Live helps create a more natural tonal balance, improved imaging, clearer dialogue, and a more cohesive surround-sound presentation.

Modern Video and Entertainment Connectivity

Seven HDMI inputs, including one conveniently located on the front panel, provide flexibility for modern televisions, projectors, gaming consoles, and streaming devices.

Compatible rear HDMI inputs support 8K/60Hz and 4K/120Hz video, with Dolby Vision, HDR10+, Variable Refresh Rate, and Auto Low Latency Mode.

Music enthusiasts will appreciate Apple AirPlay 2, Chromecast built-in, Bluetooth, and access to supported network streaming services.

A dedicated moving-magnet phono input allows a compatible turntable to become part of the entertainment system.

Designed for Custom Installation

Integra has developed the DRX-5.4 with the needs of professional integrators in mind.

Web-based setup, onboard HDMI diagnostics, IP and RS-232 control, and compatibility with supported remote monitoring systems help simplify installation, configuration, and ongoing system management.

Its integration capabilities make the DRX-5.4 an excellent choice for sophisticated home theaters and multiroom entertainment systems where dependable operation and ease of use matter.

Key Features

• 9.2-channel network AV receiver

• Nine channels of built-in amplification

• 120 watts per channel into 8 ohms, 20Hz–20kHz, two channels driven

• Up to 11.2-channel processing and preamplifier outputs

• Supports 5.2.4 and 7.2.2 Dolby Atmos configurations

• Expandable to 7.2.4 with external amplification

• Dolby Atmos and DTS

• THX Certified Select

• IMAX Enhanced

• Full-bandwidth Dirac Live room correction included

• Seven HDMI inputs, including one front-panel input

• Two HDMI outputs with main eARC support

• 8K/60Hz and 4K/120Hz video support on compatible inputs

• Dolby Vision, HDR10+, VRR, and ALLM

• Klipsch Optimize Mode for compatible speakers

• Apple AirPlay 2 and Chromecast built-in

• Bluetooth and network audio streaming

• Works with Sonos using compatible external Sonos hardware

• Roon Tested

• Moving-magnet phono input

• Zone 2 and Zone 3 capabilities

• Web-based configuration and onboard HDMI diagnostics

• IP and RS-232 control

• OvrC Pro and Domotz remote-monitoring compatibility

• Optional rack-mount kit

• Black finish

Technical Specifications

• Amplifier Channels: 9

• Processing Capability: 11.2 channels

• Power Output: 120W/channel into 8 ohms, 20Hz–20kHz, 0.08% THD, two channels driven

• THX Certification: THX Certified Select

• HDMI Inputs: 7 (6 rear, 1 front)

• HDMI Outputs: 2

• Dimensions: 17.13" W × 7.81" H × 15.31" D

• Weight: 30.9 lbs

• Finish: Black
