NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER

NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER

$3,899.00
Skip to product information
NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER
NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER

NAD CI 16-60 DSP V2v MULTI-CHANNEL NETWORK POWER AMPLIFIER

CALL FOR PRICE

513-793-3737

The NAD CI 16-60 V2 Multi-Channel Amplifier designed specifically for modern custom installation systems. Delivering sixteen channels of clean, efficient power, the CI 16-60 V2 is a perfect match for the NAD CI580v2 Four Zone Network Music Player, making a high quality but extremely cost effective combination for distributed audio and system, where reliability and consistency are critical. NAD’s HybridDigital™ amplification ensures stable performance with reduced heat and energy consumption, making it well suited for continuous operation. With simple set up via the web UI, flexible channel configuration, and dependable sound quality, the CI 16-60 V2 provides a robust amplification platform for scalable whole-home and commercial audio systems.

Key Features:

  • 16 channels of HybridDigital amplification for distributed audio systems
  • 60 watts per channel into 8 ohms
  • Bridgeable channel pairs for high-power output when required
  • Rack-mount chassis for space-efficient installations
  • Optimized for continuous, long-term operation
  • Line-level inputs and loop outs forflexible system compatibility
  • Automation-friendly trigger and control options
  • Designed for scalability in large multi-zone systems

GENERAL
Continuous output power into 8 ohms 60 W (all channels driven, 1kHz 0.05% THD
into 4 ohms 65 W (all channels driven, 1kHz 0.05% THD
Continuous output power into 8 ohms at Bridged mode 140 W (all channels driven, 1kHz 0.05% THD
THD (1 W to 50 W, 8 ohms and 4 ohms) 0.05 % (20 Hz – 3 kHz)
Signal-to-Noise Ratio 80 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power (all channels driven) 60 W (1 kHz 8 ohms 1 % THD)
Clipping power into 8 ohms at Bridged mode 150 W (1 kHz 1 % THD - all channels driven)
IHF Dynamic Power (all channels driven) 8 ohms: 65 W
IHF Dynamic Power (two channels driven) 8 ohms: 70 W
IHF dynamic power (Bridged mode, all channels driven) 8 ohms: 270 W
IHF Dynamic Power (two channels driven) 8 ohms: 280 W
Peak output current 15 A (1 ohm, 1 ms)
Damping factor 110 (20 Hz to 1 kHz 8 ohms)
Frequency response ±1dB (20 Hz - 20 kHz)
Channel separation 60 dB (1 kHz)
Maximum undistorted input level 2900 mV
Input sensitivity (for 50 W in 8 ohms, maximum volume) 760 mV
Input impedance 20 kohms//220pF
Analog input audio sense threshold (one channel with signal) 3 ± 0.5 mVrms (ref. 100 Hz - 10 kHz)
Trigger IN level 3 - 30 Vdc
Standby power 0.5W

DIMENSION AND WEIGHT
Gross dimensions (W x H x D)* 483x100x435mm
Net Weight 10.3 kg (22.7 lbs)
Shipping Weight 12.8 kg (28.2 lbs)
