NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER

NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER

$4,599.00
Skip to product information
NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER
  • NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER
NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER

NAD CI 8-150 DSP v2 MULTI-CHANNEL NETWORK POWER AMPLIFIER

CALL FOR PRICE

513-793-3737

The NAD CI 8-150 DSP V2 Multi-Channel Amplifier is designed to deliver the most refined audio performance to the rack space. Powerful, controlled sound with precision required for the most demanding installated audio systems. With eight channels of high- performance amplification and onboard digital signal processing, it provides installers with the tools to optimise audio for each zone and loudspeaker. Built on NAD’s HybridDigital™ amplification platform, the CI 8-150 DSP V2 delivers clean, efficient power while maintaining stability during continuous operation.

Key Features:

  • 8 channels of Hybrid Digital amplification with custom
    Hypex nCore output stages, for high end distributed audio and home theatre systems
  • 150 watts per channel Full Disclosure Power -  continuous into 8 ohms, all channels running.
  • Setup and configuration via intuitive webUI
  • Integrated DSP for system optimization
  • Bridgeable channel pairs for high-power configurations
  • Rack-mount chassis for professional installations Line-level & Digital inputs
  • Flexible power options via signal sense and 12v trigger

GENERAL
Continuous output power into 8 ohms 150 W (ref. 20 Hz-20 kHz at rated THD - all channels driven)
Continuous output power into 4 ohms 180 W (ref. 20 Hz-20 kHz at rated THD - all channels driven)
Continuous output power into 8 ohms at Bridged mode 280 W (ref. 20 Hz-20 kHz 0.02% THD - all channels driven)
THD (20 Hz – 20 kHz) 0.02% (1 W to 120 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio 90 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power (All channels driven) 160W(1kHz8ohms 0.1%THD)
Clipping power into 8 ohms at Bridged mode 300 W (1 kHz 0.1 % THD - all channels driven)
IHF Dynamic Power (all channels driven) - 8 Ohms 180W
IHF Dynamic Power (all channels driven) - 4 Ohms 280W
IHF Dynamic Power (two channels driven) - 8 Ohms 200W
IHF Dynamic Power (two channels driven) - 4 Ohms 360W
IHF Dynamic Power (Bridged mode, All channels driven) - 8 Ohms 520W
IHF Dynamic Power (Bridged mode, All channels driven) - 4 Ohms 670W
IHF Dynamic Power (Bridged mode, Two channels driven) - 8 Ohms 600W
IHF Dynamic Power (Bridged mode, Two channels driven) - 4 Ohms 800W
Peak output current 26A(1ohm,1ms)
Damping Factor 150 (ref. 8 ohms, 20 Hz to 6.5 kHz)
Frequency Response ±0.5dB(20Hz-20kHz)
Channel Seperation 75 dB (1 kHz)
Maximum undistorted input level 3300 mV
Input sensitivity (for 150 W in 8 ohms, maximum volume) 1450 mV
Analog Input audio sense threshold (one channel with signal) 3 ± 0.5 mVrms (ref. 100 Hz - 10 kHz)
Trigger IN level 3-30Vdc
Standby power 0.5 W

DIMENSION AND WEIGHT
Gross dimensions (W x H x D)* 483x90x435mm
Shipping Weight 17.6 kg (38.8 lbs)
