REGA Elicit R Mk5

The Elicit MK5 stereo integrated amplifier is designed and built to the highest standard. Housed in our latest custom case to match the rest of the Rega range, the MK5 builds on previous Rega designs by using our multi-award-winning Class A/B power amplifier circuit to deliver a powerful 105 W per channel into 8 Ω loads (127 W into 6 Ω). Our engineers have designed a new Rega DAC circuit offering digital connectivity and greater integration with a variety of other products. We have taken great care to incorporate a high-quality MM phono stage and the headphone output has been configured such that the speaker switching is performed by the output mute relay to avoid obstructing the signal path.

Key Features

• 105 W per channel into 8 Ω
• High quality moving magnet phono stage
• 2 x Digital inputs - 1 x optical and 1 x Co-Axial
• High performance Rega DAC circuit for digital inputs
• 4 Line level inputs
• Headphone output
• Direct Input
• Record input
• New advanced pre-amplifier
• Alps volume potentiometer
• Thermal Cut-Out
• Lifetime warranty against manufacture defects

Technical Specs

Power Outputs at rated 230/115 V Supply voltage

105 W per channel into 8 Ω
127 W per channel into 6 Ω
162 w per channel into 4 Ω

Power Consumption

375  W

Power Consumption in ‘off mode’

0.0 W

Dimensions (W × H × D)

432 x 82 x 340 (D includes loudspeaker terminals)

17.01 × 3.23 × 13.39 inches

Weight

12.5Kg (27.56 lbs)

Supported Sampling Rates kHz

32, 44.1, 48, 88.2, 96, 176.4, 192kHz

Supported Bit Depths

16 to 24 bit

Power Management

For best audio performance this product needs to reach an optimum temperature for the bias current to stabilise. Therefore, this product does not include a power management function Please note: leaving this product on for long periods will result in increased energy consumption.
